Models for delivery: |
---|
TMG-25/6(10)/0,4 N1, NF1 |
TMG-40/6(10)/0,4 N1, NF1 |
TMG-63/6(10)/0,4 N1, NF1 |
TMG-100/6(10)/0,4 N1, NF1 |
TMG-160/6(10)/0,4 N1, NF1 |
TMG-250/6(10)/0,4 N1, NF1 |
TMG-400/6(10)/0,4 N1, NF1 |
TMG-630/6(10)/0,4 N1, NF1 |
TMG-1000/6(10)/0,4 N1, NF1 |
TMG-1250/6(10)/0,4N1, NF1 |
TMG-1600/6(10)/0,4 N1, NF1 |
TMG-2500/6(10)/0,4 У1, ХЛ1 |
1. General characteristics:
2. Assignment:
Hermetic three-phase oil transformers type TMG with corrugated tank, with natural oil cooling, with non-excitation regulating to be included in the network of alternating current with frequency of 50 Hz, intended for transmission and distribution of electricity in the conditions of temperate and cold climate. Transformers are not designed to operate under conditions of shock, vibration, explosive, and reactive environment. In the manufacture of transformers TMG applied technical solutions that increase reliability and reduce operating costs.
Transformers made in a hermetically sealed version with complete filling of the oil. There is no extender and the gas cushion. The temperature change of oil volume is compensated by the volume change of the corrugations of the tank due to plastic deformations. The advantage of sealed transformers is that the oil has no direct contact with the atmosphere, eliminating the ingress of moisture from the environment.
The transformers meet the requirements of GOST 11677 and technical condition 5100 RK 0001 0033 AO-017-2005. Voltage is regulated non-excitation. This transformer has a high voltage switches, which are connected to the high voltage winding and allow you to adjust the voltage levels when disconnected from the network transformer by LV and HV with a range of ±2×2.5% of
3. Conditions:
4. Construction of transformers:
Tanks transformers rectangular. Below are the plug for draining the oil, the valve (tube) for oil filling, grounding bolt. On the lid of the tank are the HV, LV, oil gauge, safety valve, socket thermometer and earrings for lifting the transformer.
The active part consists of a magnetic core made of cold-rolled electrical steel coils and switch. A special form of execution of the magnetic circuit allows you to create a connection called «STEP-LAP», which proved to be excellent low noise and low no-load losses. The transformer winding is made of aluminum or copper wires up to 250 KVA and above the LV winding of the foil. When winding coils as an insulating material is paper stamps PID, which after drying, the finished coils in the dryer, very tight hugs used conductor, thereby increasing the resistance of the winding to the electrodynamic efforts that occur after short circuit.
The HV and LV outdoor installation, removable, bushings and porcelain. At a current of 1000 a and higher in the upper part of the conductive rod is attached a special terminal with a shovel, which provide connecting flat tires.
In transformers with capacity from 100 to 2500 kVA rollers are installed in the order that is used for longitudinal and transverse movement of the transformers.
1. Capacity from 25 to 100 kVA:
Тип | Windings' connection | Po, kW | Pk, kW | Uk, % | Io, % |
---|---|---|---|---|---|
TMG-25/6(10) | Y/Yn-0 Y/Zn-11 | 0.11 | 0.6 0.69 | 4.5 4.7 | 2.2 |
TMG-40/6(10) | Y/Yn-0 Y/Zn-11 | 0.15 | 0.88 1.0 | 4.5 4.7 | 2.0 |
TMG-63/6(10) | Y/Yn-0 Y/Zn-11 | 0.21 | 1.28 1.47 | 4.5 4.7 | 1.8 |
TMG-100/6(10) | Y/Yn-0 Y/Zn-11 D/Yn-11 | 0.27 | 1.9 2.25 2.25 | 4.5 4.7 4.5 | 1.6 |
2. Capacity from 160 to 630 kVA:
Тип | Windings' connection | Po, kW | Pk, kW | Uk, % | Io, % |
---|---|---|---|---|---|
TMG-160/6(10) | Y/Yn-0 Y/Zn-11 D/Yn-11 | 0.41 | 2.6 2.9 2.9 | 4.5 4.7 4.5 | 1.4 |
TMG-250/6(10) | Y/Yn-0 Y/Zn-11 D/Yn-11 | 0.47 | 3.7 4.2 4.2 | 4.5 4.7 4.5 | 1.2 |
TMG-400/6(10) | Y/Yn-0 Y/Zn-11 D/Yn-11 | 0.72 | 5.5 5.9 5.9 | 4.5 | 1.0 |
TMG-630/6(10) | Y/Yn-0 Y/Zn-11 | 1.0 | 7.6 | 5.5 | 0.6 |
3. Capacity from 1000 to 2500 kVA:
Тип | Windings' connection | Po, kW | Pk, kW | Uk, % | Io, % |
---|---|---|---|---|---|
TMG-1000/6(10) | Y/Yn-0 Y/Zn-11 | 1.4 | 10.8 | 5.5 | 0.6 |
TMG-1250/6(10) | Y/Yn-0 Y/Zn-11 | 1.5 | 14.35 | 6.0 | 0.5 |
TMG-1600/6(10) | Y/Yn-0 Y/Zn-11 | 1.7 | 17.3 | 6.0 | 0.5 |
TMG-2500/6(10) | Y/Yn-0 Y/Zn-11 | 2.5 | 28.0 | 6.5 | 0.4 |
1. Capacity from 25 to 100 kVA:
Power | L | B | H | K | M | h | h1 | A | A1 | Weight | Oil |
---|---|---|---|---|---|---|---|---|---|---|---|
25 kVA | 840 | 520 | 970 | 170 | 90 | 85 | 95 | 450 | 400 | 285 kg | 84 kg |
40 kVA | 880 | 525 | 1050 | 170 | 90 | 85 | 100 | 450 | 400 | 355 kg | 95 kg |
63 kVA | 945 | 565 | 1100 | 170 | 90 | 85 | 110 | 500 | 400 | 430 kg | 116 kg |
100 kVA | 980 | 640 | 1230 | 190 | 90 | 105 | 105 | 550 | 450 | 580 kg | 160 kg |
2. Capacity from 160 to 630 kVA:
Power | L | B | H | K | M | h | h1 | A | A1 | Weight | Oil |
---|---|---|---|---|---|---|---|---|---|---|---|
160 kVA | 1075 | 730 | 1260 | 190 | 90 | 115 | 105 | 550 | 550 | 755 kg | 175 kg |
250 kVA | 1180 | 760 | 1280 | 190 | 110 | 110 | 115 | 550 | 550 | 1010 kg | 260 kg |
400 kVA | 1365 | 830 | 1330 | 230 | 150 | 130 | 130 | 660 | 660 | 1400 kg | 375 kg |
630 kVA | 1490 | 880 | 1585 | 230 | 150 | 155 | 155 | 660 | 660 | 1960 kg | 480 kg |
3. Capacity from 1000 to 2500 kVA:
Power | L | B | H | K | M | h | h1 | A | A1 | Weight | Oil |
---|---|---|---|---|---|---|---|---|---|---|---|
1000 kVA | 2005 | 1240 | 1775 | 230 | 145 | 200 | 180 | 820 | 820 | 3175 kg | 730 kg |
1250 kVA | 1995 | 1320 | 1960 | 250 | 210 | 180 | 160 | 820 | 820 | 3950 kg | 980 kg |
1600 kVA | 1995 | 1320 | 2050 | 250 | 210 | 180 | 160 | 1070 | 1070 | 3980 kg | 1100 kg |
2500 kVA | 2270 | 1530 | 2160 | 260 | 145 | 220 | 170 | 1070 | 1070 | 5650 kg | 1250 kg |
